Nhà sản xuất chuyên nghiệp của nhiều loại máy thổi

|
| Place of Origin: | CHINA |
| Hàng hiệu: | BK |
| Chứng nhận: | ISO9001/ISO14001 |
| Model Number: | XTB600HP |
| Minimum Order Quantity: | 1 |
|---|---|
| Giá bán: | Có thể đàm phán |
| Packaging Details: | Exported wooden case |
| Delivery Time: | 25 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 300 sets / month |
| Flow Rate: | 207-390 m³/min | Cooling way: | Air |
|---|---|---|---|
| Size: | W1800mm* D3500mm* H2200mm | Discharge: | 500mm |
| Applications: | Oxygen and cement Transportation, water treatment,chemical transportation | Model: | XTB600HP |
| Weight: | 3860 kg | Advantages: | Intelligent control, Low noise,Small vibration, Remote control |
Product Components
| Touch screen LCD | Variable frequency drive | Cooling air muffler |
1,Input driving signal 2,View operational data 3,Change product settings | 1,Change the motor speed according to the PLC value | 1,Saving installation space 2,Two air cooling circulation systems |
| Vent valve | Air | Internal Muffler |
1,Empty the air to protect the motor when starting and stopping the blower | 1,Compress the surrounding air and gas | 1,Reduce the noise transmitted to the outside through the motor of the entrance path |
Comparing With Other Bearings
| Item | Roller bearing | Tilting-pad bearing | Magnetic bearing | Air foil bearing |
| Lubricants | Need | Need | - | - |
| Maintenance | Need replace after a period of operation | Need regular check/replace | Need replace assistant ball bearing | No Need |
| Maintenance period | 1 year | 1 year | 5 years | 20 years |
| Power cut/ electrical failure | Oil pressure drop/ possible fault | Oil pressure drop/ possible fault | Short life of assistant ball bearing | No |
| System composition | Complex oil system | Complex oil system | Complex controller, limited bearing coil life | Easy (complete machine type) |
| Power loss | 5% loss due to gear system | 10% loss due to gear system | (When high speed motor equipped) 1% loss | (When high speed motor equipped) Loss < 0.5% |
| A/S charges | 50 | 100 | 100 | 50 |
Machine Specifications:
| Model | Pressure | Air Capacity | Discharge Bore A | Cooling Way |
| mmAq | ㎥/min | |||
| XTB600HP-0.6 | 6000 | 390 | 500 | Air cooling |
| XTB600HP-0.8 | 8000 | 307 | 500 | |
| XTB600HP-1.0 | 10000 | 252 | 500 | |
| XTB600HP-1.2 | 12000 | 207 | 500 |
Advantages of XTB Blower
(1) Energy-saving, high efficiency
Air bearing turbo centrifugal blower adopts air foil bearings, direct-connection technology, high efficiency impeller and motor. No additional friction will occur, and motor power consumption is automatically adjusted according to the output airflow capacity (adjustable range 20-100%), so the energy-saving effect is remarkable.
(2) Low noise
Adopt air bearing and direct-connection way without mechanical contact. Noise is lower,so there’s no need to install acoustic enclosure.
(3) No oil, no vibration
Adopting non mechanical contact air bearings, the centrifugal blower continuously performs suction and exhaust, and the vibration of the product itself is ZERO level.
(4) Convenient maintenance
Without gearbox and oil-lubricated bearing of traditional blowers, high and new technology is introduced for convenient maintenance
