5.0KW Submersible Mixers Wastewater QJB5.0/12-615/3-480S for cesspit clean

5.0KW Submersible Mixers Wastewater QJB5.0/12-615/3-480S for cesspit clean

    • 5.0KW Submersible Mixers Wastewater QJB5.0/12-615/3-480S for cesspit clean
    • 5.0KW Submersible Mixers Wastewater QJB5.0/12-615/3-480S for cesspit clean
  • 5.0KW Submersible Mixers Wastewater QJB5.0/12-615/3-480S for cesspit clean

    Thông tin chi tiết sản phẩm:

    Place of Origin: China
    Hàng hiệu: BK
    Chứng nhận: ISO9001/ISO14001
    Model Number: QJB5.0/12-615/3-480S

    Thanh toán:

    Minimum Order Quantity: 1 set
    Giá bán: Negotiation
    Packaging Details: Export standard wooden case
    Delivery Time: 5-20 working days, depends on order amount and specification
    Payment Terms: L/C, T/T
    Supply Ability: 200 SETS per month
    Liên hệ với bây giờ
    Chi tiết sản phẩm
    Model: QJB5.0/12-615/3-480S Motor Power: 5.5KW
    Main Materials: Stainless steel Rotary speed: 480rpm
    Diameter of Blade: 615mm Axial thrust (N)): 1800
    Application:: water treatment, applied for densification process, sludge dewatering process, heat transfer, and cesspit clean



    5.0KW Submersible Mixer QJB5.0/12-615/3-480S, submerged mixer, sludge mixer






    About QJB mixer



    QJB Series Submersible sewage mixer/submerged mixer/sludge mixer adopts excellent hydraulic design, wider type spectrum and optimized structure. Pump casing is produced by special machine tool, which ensures concentricity among shaft bearing, shaft and pump case, and provides better reliability and maintainability. Apply to municipal water supply and drainage, water circulation of air conditioner, agricultural hydraulic engineering, such as irrigation, drain flooded fields ,industrial water supply system, firefighting system, water supply and drainage of heating system, transportation of clean water ect.






    Working Conditions



    The submersible mixer can be continuous operation in the conditions as below:

    • The maximum medium temperature be less than 40℃
    • Medium PH value be in 5~9
    • Medium density be less than 1150kg/m3
    • Continuous operation, the depth be less than 20m




    Specifications



    Model No.

    QJB5.0/12-615/3-480S

    Model meaning:

    QJB—submersible mixer

    5.0—rated motor power of mixer

    12—poles of motor

    615—diameter of impeller

    3—quantity of impeller

    480—rated speed of mixer

    S—stainless steel

    Motor Power

    5.0KW

    380/400/415/440V, 3PHASES, 50/60HZ, 12 Poles

    Rated Current

    27A

    Main Materials

    Stainless steel

    Rotary speed

    480r/min

    Diameter of Blade

    615

    Axial thrust

    1800

    Installation system

    Equipped according to tank depth, standard supply scope of 4m installation system

    Including leader, leader base, lifting head, support frame, limit frame, etc.

    N.W. of mixer without installing system

    184kg






    Features



    1, QJB type low speed of thrusters compact structure, small volume, light weight. Operation simple maintenance, installation convenient and long service life.


    2, QJB type low speed of propeller blade with consecrated themselves function, can prevent sundry winding, jam.


    3, and aeration system can be used together to reduce energy consumption, oxygen filling improved obviously, effectively prevent precipitation.


    4, QJB type low speed of thrusters motor winding for class F insulation, protection grade for IP68, choose a lubrication free maintenance, import bearings with oil leak detection room and motor winding overheating protection function, make the motor work more safety and reliable.


    5, QJB type low mechanical seal of the friction thrusters pay material for corrosion resistance of tungsten carbide, all fasteners for stainless steel material.


    6, QJB type low speed thrusters under specified conditions, first failure of average running time before not less than 10000 hours, the machine service life is not less than 15 years.






    Working Principle



    The propeller blade of a special structure starts slow moving driven by the under-water motor to produce a powerful water flow flowing in a lower tangential direction to make the liquid’s power increased and produce strong stirring to reduce the precipitation under the water, thus realizing liquid stirring and flowing.






    Structure of Mixer



    5.0KW Submersible Mixers Wastewater QJB5.0/12-615/3-480S for cesspit clean




    Installation diagram



    5.0KW Submersible Mixers Wastewater QJB5.0/12-615/3-480S for cesspit clean
