Roots Rotary Lobe Blower with 3 L/min Cooling Water, 60-100KPA Discharge Pressure, and 1.5-5.5 KW Motor Power

Thông tin chi tiết sản phẩm:

Nguồn gốc:	Trung Quốc
Hàng hiệu:	BK
Chứng nhận:	ISO9001/ISO14001/CE
Số mô hình:	BKW4007

Thanh toán:

Số lượng đặt hàng tối thiểu:	1 bộ
Giá bán:	Có thể đàm phán
chi tiết đóng gói:	Vỏ gỗ tiêu chuẩn xuất khẩu
Thời gian giao hàng:	5 đến 20 ngày làm việc, tùy thuộc vào số lượng đặt hàng và thông số kỹ thuật
Điều khoản thanh toán:	L/C, T/T
Khả năng cung cấp:	100 bộ mỗi tháng

Tiếp xúc

Chi tiết sản phẩm

Tên:	Máy thổi thùy quay Roots	Kiểu:	Loại Rễ chuyển vị dương, ba thùy
Khả năng không khí:	0,8-1,87m³/phút	Xả áp suất chênh lệch:	60-100KPA
Công suất động cơ:	1,5-5,5kw	Khoan xả:	DN50 (2”)
Loại điều khiển:	Động cơ điều khiển, được kết nối bởi vành đai và ròng rọc	Kiểu cài đặt:	Dọc, ngang cũng có sẵn
Trọng lượng (Không có động cơ):	92 kg	Tốc độ:	1650-2200 vòng/phút
nước làm mát:	3 lít/phút	Công suất trục:	2,34-4,39KW
Làm nổi bật:	3 L/min Cooling Water Roots Blower , 60-100KPA Discharge Pressure Tri-Lobe Blower , 1.5-5.5 KW Motor Power Roots Rotary Lobe Blower

Min.Pressure 0.6 kgf/cm² ,DN50,Cooling Water 3 L/min, Positive Water Treatment Roots Blower

On the base of introduced technology from American, we developed BKW Series Roots blowers with tri-lobes and water cooling structure. The blower unit has a compact construction including blower, motor, inlet and discharge silencers, filter, flexible joints, relesf valve, check valve, and pressure gauge, and also can be equipped with acoustic enclosure and control devices.

Specifications

Model	BKW4007
Air capacity	0.8-1.87m³/min
Discharge differential pressure	60-100KPA
Rotary speed	1650-2200rpm
Cooling water volume	3 L/min
Motor type	1.5-5.5KW 380/400/415/440V, 3PHASES, 50/60HZ
Motor brand	Standard: Siemens Beide or Wannan motor Siemens and other motors for your option
Installation type	Standard: horizontal type. Vertical type available for your option
N.W. of blower without motor	92kg
Packing size Approx.	Packing case for blower: 1.10.81.1m (LWH)

Applications

1. aeration waste water treatment

2. backwashing in sewage treatment

3. pneumatic conveying in cement plants

4. dust removal in power plant

Parameter sheet

Model	Speed	Inlet capacity (m3/min)and shaft power (KW)										Cooling water
		0.6kgf/cm2		0.7kgf/cm2		0.8kgf/cm2		0.9kgf/cm2		1.0kgf/cm2
		6000mmH2O		7000mmH2O		8000mmH2O		9000mmH2O		10000mmH2O
		0.06Mpa		0.07Mpa		0.08Mpa		0.09Mpa		0.1Mpa
	rpm	m3/min	KW	m3/min	KW	m3/min	KW	m3/min	KW	m3/min	KW	L/min
BKW4007	1650	1.05	2.34	0.94	2.58							3
BKW4007	1750	1.20	2.48	1.09	2.73	0.99	2.99	0.89	3.24	0.80	3.49
Port Dia: DN50(2")	1850	1.35	2.62	1.24	2.89	1.13	3.16	1.04	3.42	0.94	3.69
	1950	1.50	2.76	1.39	3.05	1.28	3.33	1.18	3.61	1.09	3.89
	2100	1.72	2.98	1.61	3.28	1.50	3.58	1.41	3.89	1.31	4.19
	2200	1.87	3.12	1.76	3.44	1.65	3.75	1.55	4.07	1.46	4.39

Structure of blower main body

Roots Rotary Lobe Blower with 3 L/min Cooling Water, 60-100KPA Discharge Pressure, and 1.5-5.5 KW Motor Power 0

Flow direction of cooling water

Roots Rotary Lobe Blower with 3 L/min Cooling Water, 60-100KPA Discharge Pressure, and 1.5-5.5 KW Motor Power 1

Assembling drawing of blower package

Roots Rotary Lobe Blower with 3 L/min Cooling Water, 60-100KPA Discharge Pressure, and 1.5-5.5 KW Motor Power 2

Outline Dimension

Roots Rotary Lobe Blower with 3 L/min Cooling Water, 60-100KPA Discharge Pressure, and 1.5-5.5 KW Motor Power 3 BKW Outline Dimension Sheet Unit:mm
Type
Port Dia
Motor power A B C D E F G H K M N 0 P Q 4-M16×h
Weight
(kg) BKW4007 50(2") 1.5～5.5 820 640 90 90 457 185 236 872 151 370 440 105 130 18 4-M16×300 92 Standard accssory include:Inlet and outlet silencer,pressure gauge,base-frame,blower's pulley,motor'spulley,belt,belt guard,relief valve,check valve. The weight above are for standard accessories only,motor excluded. Dimension for blower,which is equipped with high voltage motor,will be supplied specially.

FAQ

Q1. Are you manufacturer or trading company?

We are the professional machinery manufacturer.Now the company has formed an annual production and sales scale of more than 30000 sets of blowers and water pumps.

Q2: Where is your factory located? May I have a visit?

Warmly welcome! Our factory is located in the Industrial Park for Environmental Science and Technology , Yixing, China.

Q3:What's the information should I provide when inquiry?
A: Air capacity
B: Pressure
C: Application
D: Use environment(Temperature, atmospheric pressure)
E: Do you need motor?
Or other specials you give us will be more appreciated.

Q4: What is your warranty?
Our warranty is 12 months after received the machine.

Q5. What is your terms of packing?
A: Generally, we pack our goods in Fumigation Free Plywood Case. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.

Q6. How does your factory control product quality?
We have quality inspection department. Before sending out product, we check each product. If there is quality problem, we will produce new one.

Q7. What are your terms of payment?
TT 30% as the advance payment and TT 70% after inspection before shipping.
