DN50(2") 1.09-2.54 m³/min Corrosion-proof Water Cooling Blower 10-70 KPA

Thông tin chi tiết sản phẩm:

Nguồn gốc:	TRUNG QUỐC
Hàng hiệu:	BK
Chứng nhận:	ISO9001/ISO14001
Số mô hình:	YU-EG50

Thanh toán:

Số lượng đặt hàng tối thiểu:	1 bộ
Giá bán:	Có thể đàm phán
chi tiết đóng gói:	Vỏ gỗ tiêu chuẩn xuất khẩu
Thời gian giao hàng:	15 đến 30 ngày làm việc, tùy thuộc vào số lượng đặt hàng và thông số kỹ thuật
Khả năng cung cấp:	20 bộ mỗi tháng

Tiếp xúc

Chi tiết sản phẩm

Dung tích:	1,09-2,54m³/phút	Xả áp suất chênh lệch:	10-70KPA
Kích thước lỗ:	DN50(2”)	Loại làm mát:	Nước
Kiểu kết nối:	Đai lái xe	đai và ròng rọc:	Vận chuyển khí sinh học, khí thải, chất nổ
nước làm mát:	3 lít/phút	Tốc độ:	1500-2100 vòng/phút
Sức mạnh trục:	1,04-3,28 KW

Roots type Biogas Blower DN50 anti-corrosive, explosion-proof

About YU-EG

A new type blower designed by our company, impeller and internal surface with special coating, capable of handling particular gases with acids, alkalis, corrosive, inflammable or explosive materials.

Specifications

Model	YU-EG50
Air capacity	1.09-2.54m³/min
Discharge differential pressure	10-70KPA
Rotary speed	1500-2150rpm
Cooling water volume	3 l/min
Motor type	1.5-5.5KW 380/400/415/440V, 3PHASES, 50/60HZ, explosion-proof type motor
Motor brand	Standard: Siemens Beide or Wannan motor Siemens and ABB motor for your option
Installation type	Standard: vertical type
N.W. of blower without motor	105kg
Packing size Approx.	1.760.4271.225m (lengthwidthheight)
Features	1. Suitable for flammable and corrosive gas because of its explosion proof and antisepsis performance 2. Equipped with multiply seal to prevent leakage 3. Sprayed with special antisepsis material on cylinder and cover.

Parameter sheet

Model	Port	Inlet capacity (m3/min)and shaft power (kW) under various pressure									Cooling water
		Speed	0.1kgf/cm2		0.2kgf/cm2		0.3kgf/cm2		0.4kgf/cm2
			1000mmH2O		2000mmH2O		3000mmH2O		4000mmH2O
			0.01Mpa		0.02Mpa		0.03Mpa		0.04Mpa
			m3/min	KW	m3/min	KW	m3/min	KW	m3/min	KW	(l/min)
YU-EG50	50(2")	1500	1.65	1.04	1.42	1.26	1.24	1.48	1.09	1.69	3
		1650	1.88	1.15	1.64	1.38	1.46	1.62	1.31	1.86
		1750	2.02	1.22	1.79	1.47	1.61	1.72	1.46	1.97
		1850	2.17	1.28	1.94	1.55	1.76	1.82	1.60	2.09
		1950	2.32	1.35	2.09	1.64	1.90	1.92	1.75	2.20
		2100	2.54	1.46	2.31	1.76	2.13	2.07	1.97	2.37

Model	Port	Inlet capacity (m3/min)and shaft power (kW) under various pressure									Cooling water
		Speed	0.5kgf/cm2		0.6kgf/cm2		0.7kgf/cm2		0.8kgf/cm2
			5000mmH2O		6000mmH2O		7000mmH2O		8000mmH2O
			0.05Mpa		0.06Mpa		0.07Mpa		0.08Mpa
			m3/min	KW	m3/min	KW	m3/min	KW	m3/min	KW	(l/min)
YU-EG50	50(2")	1500									3
		1650	1.17	2.10
		1750	1.32	2.23	1.20	2.48	1.09	2.73
		1850	1.47	2.35	1.35	2.62	1.24	2.89
		1950	1.62	2.48	1.50	2.76	1.39	3.05
		2100	1.84	2.67	1.72	2.98	1.61	3.28

Structure of blower main body

DN50(2") 1.09-2.54 m³/min Corrosion-proof Water Cooling Blower 10-70 KPA 0

Assembling drawing of blower package

DN50(2") 1.09-2.54 m³/min Corrosion-proof Water Cooling Blower 10-70 KPA 1

Standard supply of scope

1. shaft blower

2. vacuum pressure relieve valve

3. check valve

4. inlet silencer(with filter)

5. discharge silencer

6. public base (with belt cover)

7. rubber flexible joint and shock pad

8. pulley

9. pressure gauge

10. belt

11. bolts and nuts and other connection parts

12. motor

FAQ

1. What's the information should I provide when inquiry?
A: Air capacity
B: Pressure
C: Application
D: Use environment(Temperature, atmospheric pressure)
E: Do you need motor?
Or other specials you give us will be more appreciated.

2. What is your warranty?
Our warranty is 12 months after received the roots blower. During the warranty period, replace the damaged parts for free of charge. Out warranty period, to provide timely, high-quality technical services and price concessions spare parts to ensure continuous safe and high-quality equipment operation.

3. How long is the service life of roots blower?
In normal use environment
A- Service life of blower is more than 10 years.
B- Service life of Impeller is more than 60, 000 hours.
C- Service life of bearing is more than 50, 000 hours.
D- Service life of gear is more than 60, 000 hours.

4. What is your terms of packing?
A: Generally, we pack our goods in Fumigation Free Plywood Case. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.

5. How does your factory control product quality?
We have quality inspection department. Before sending out product, we check each product. If there is quality problem, we will produce new one.

6. What are your terms of payment?
1. TT30% as the advanced payment and TT 70% after inspection before shipping.
2.100% irrevocable L/C at stght.
